Drive-In J-Hooks

Description

What It Does

Provides cable, hose, and pipe support using an integrated drive-in mounting design.

Why Customers Choose It

• Fast installation into wood and similar materials
• Eliminates the need for additional mounting hardware

Common Applications

• Wooden structures
• Utility poles
• Construction projects
• General support applications

Practical Use Case

Drive-In J-Hooks are typically used when cable support is needed on wooden structures where drilling and bolting may be unnecessary or impractical. The mounting design functions similarly to a nail, allowing the hanger to be driven directly into wood for quick installation without additional mounting hardware.

Product Details

Part NumberCarrierDiameterLengthCore MaterialMount StyleWorking LoadBox QtyBox WeightItem Weight
CAB 3531-Carrier3 in. (76 mm)5 in. (127 mm)7G x 1 in. Steel3 in. (76 mm) Drive-in87 lbs. (39 kg)2517 lbs. (7.7kg)
CAB 4621-Carrier4 in. (102 mm)6.75 in. (172 mm)7G x 1 in. Steel4.25 in. (108 mm) Drive-in60 lbs. (27 kg)2521 lbs. (9.5kg)
CAB 4791-Carrier5 in. (127 mm)8.5 in. (216 mm)7G x 1 in. Steel4.25 in. (108 mm) Drive-in40 lbs. (18 kg)2530 lbs. (13.6 kg)

Ask Us About Our Customized Solutions
